| Краткое название |
Мощность LD (кВт) |
Ток LD (А) |
Мощность ND (кВт) |
Ток ND (А) |
Мощность HD (кВт) |
Ток HD (А) |
Габариты (Ш×В×Г, мм) |
Вес (кг) |
| FR-F840-00023 | 0,4 | 0,8 | — | — | 0,2 | 0,6 | 108 × 128 × 129,5 | 1,2 |
| FR-F840-00038 | 0,75 | 1,4 | — | — | 0,4 | 1,0 | 108 × 128 × 129,5 | 1,2 |
| FR-F840-00052 | 1,5 | 2,0 | — | — | 0,75 | 1,5 | 108 × 128 × 129,5 | 1,2 |
| FR-F840-00083 | 3,7 | 7,6 | 2,2 | 4,6 | 1,5 | 3,5 | 108 × 128 × 135 | 1,5 |
| FR-F840-00126 | 5,5 | 11,5 | 3,7 | 7,5 | 2,2 | 5,5 | 140 × 150 × 135 | 1,9 |
| FR-F840-00170 | 7,5 | 17,0 | 5,5 | 12,0 | 3,7 | 9,5 | 140 × 150 × 135 | 1,9 |
| FR-F840-00250 | 11,0 | 22,5 | 7,5 | 17,0 | 5,5 | 12,0 | 220 × 300 × 190 | 8,3 |
| FR-F840-00310 | 15,0 | 29,0 | 11,0 | 23,0 | 7,5 | 17,0 | 220 × 300 × 190 | 8,3 |
| FR-F840-00380 | 18,5 | 35,0 | 15,0 | 29,0 | 11,0 | 23,0 | 220 × 300 × 190 | 8,3 |
| FR-F840-00470 | 22,0 | 47,0 | 18,5 | 38,0 | 15,0 | 29,0 | 250 × 400 × 190 | 15,0 |
| FR-F840-00620 | 30,0 | 62,0 | 22,0 | 47,0 | 18,5 | 38,0 | 250 × 400 × 190 | 15,0 |
| FR-F840-00770 | 37,0 | 77,0 | 30,0 | 62,0 | 22,0 | 47,0 | 325 × 550 × 300 | 24,0 |
| FR-F840-00930 | 45,0 | 93,0 | 37,0 | 77,0 | 30,0 | 62,0 | 325 × 550 × 300 | 24,0 |
| FR-F840-01160 | 55,0 | 116,0 | 45,0 | 93,0 | 37,0 | 77,0 | 465 × 740 × 360 | 74,0 |
| FR-F840-01800 | 75,0 | 180,0 | 55,0 | 116,0 | 45,0 | 93,0 | 465 × 740 × 360 | 74,0 |
| FR-F840-02160 | 90,0 | 216,0 | 75,0 | 180,0 | 55,0 | 116,0 | 680 × 1010 × 380 | 166,0 |
| FR-F840-02600 | 110,0 | 260,0 | 90,0 | 216,0 | 75,0 | 180,0 | 680 × 1010 × 380 | 166,0 |
| FR-F840-03250 | 132,0 | 325,0 | 110,0 | 260,0 | — | — | — | — |
| FR-F840-03610 | 160,0 | 361,0 | 132,0 | 325,0 | — | — | — | — |
| FR-F840-04320 | 200,0 | 432,0 | 160,0 | 361,0 | — | — | — | — |
| FR-F840-04810 | 220,0 | 481,0 | 200,0 | 432,0 | — | — | — | — |
| FR-F840-05470 | 250,0 | 547,0 | 220,0 | 481,0 | — | — | — | — |
| FR-F840-06100 | 280,0 | 610,0 | 250,0 | 547,0 | — | — | — | — |
| FR-F840-06830 | 355,0 | 683,0 | 315,0 | 610,0 | — | — | — | — |
LD — Light Duty (120% 60 с / 150% 3 с); ND — Normal Duty (150% 60 с / 200% 3 с); HD — Heavy Duty (200% 60 с / 250% 3 с). Указан диапазон питающего напряжения 380…500 В (3 фазы). Габариты и масса соответствуют стандартному исполнению IP20. Для старших моделей (от 132 кВт) данные по массе и габаритам уточняйте в расширенной документации Mitsubishi Electric.
